See The Unseeable
A property can appear perfectly sound to the naked eye while concealing hidden defects beneath the surface. Thermal imaging allows us to identify temperature differences that may indicate heat loss, insulation defects, moisture intrusion, cold bridging or overheating electrical components that would otherwise remain undetected during a conventional visual inspection.
Using our professional FLIR thermal imaging camera, we can provide an enhanced level of inspection alongside your Level 2 Home Buyer Survey or Level 3 Building Survey for just £20.
Unlike standalone thermal surveys, our thermal imaging inspection is interpreted alongside the property's construction, age and condition. This allows us to place the thermal images into context and explain what they are likely to indicate within your written survey report.
Thermal imaging works by detecting infrared energy rather than visible light. Every building material emits heat at different levels, allowing temperature variations to become visible as colour patterns. These differences can highlight potential defects long before visible signs appear.
Typical findings include:
• Missing or poorly installed loft insulation
• Cold air entering around doors and windows
• Areas of significant heat loss
• Cold bridging through walls and structural elements
• Damp affected areas displaying abnormal thermal patterns
• Overheating electrical sockets, switches or consumer units
• Uneven heating performance
• Poorly insulated extensions and roof spaces
Although thermal imaging is an extremely useful investigative tool, it does not directly diagnose defects on its own. The images must always be interpreted by an experienced surveyor who understands how buildings behave, how moisture moves through structures and how environmental conditions influence thermal patterns.
At DB Property Surveyors, every thermal image is assessed alongside moisture readings, visual observations and the property's method of construction. This produces a far more accurate assessment than relying on thermal images alone.
FAQ Section
Is thermal imaging included in every survey?
No. Thermal imaging is an optional enhancement available for both our Level 2 HomeBuyer Surveys and Level 3 Building Surveys for just £20.
Can thermal imaging detect damp?
Thermal imaging cannot confirm damp on its own, but it can identify unusual temperature patterns that may indicate moisture. These findings are assessed alongside moisture meter readings and the surveyor's inspection.
Can thermal imaging detect heat loss?
Yes. It is particularly effective at identifying missing insulation, cold bridging and unwanted air leakage around doors, windows and roof spaces.
Can thermal imaging find electrical faults?
It can highlight unusually warm electrical components that may warrant further investigation by a qualified electrician. It is an excellent screening tool but is not a substitute for an Electrical Installation Condition Report (EICR).
Does weather affect thermal imaging?
Yes. Thermal imaging is most effective when there is a sufficient temperature difference between the inside and outside of the property. External weather conditions and ambient temperatures can influence the results, which is why all findings are interpreted by an experienced surveyor.
